SC450AI
4MP, 2688×1520, 4-lane. Command: bash install.sh sc450ai
These fourteen modules have a tested driver. Install from RPI5_MIPI_DRIVERS, then open the picture in a browser. Each card links to that camera's folder. Cards with a product page also link to the shop. For the IMX908, the OV5640, and the SC835HAI, contact Camemake.
4MP, 2688×1520, 4-lane. Command: bash install.sh sc450ai
5MP RGB-IR, 2592×1944, 4-lane. The preview looks magenta. Command: bash install.sh ox05b1s
2.5MP, 2560×1440, 2-lane. Command: bash install.sh gc4023
2MP, 1928×1088, 2-lane. Command: bash install.sh hm2170
2MP global shutter, 1920×1200, 4-lane. Command: bash install.sh sc233hgs
5MP, 2608×1960, 2-lane. Command: bash install.sh imx675
48MP sensor in the tested 4000×3000 mode, 4-lane. Command: bash install.sh imx586
1MP mono global shutter, 1280×800, 2-lane. The preview is gray. Command: bash install.sh ov9281
2.3MP color global shutter, 1920×1200, 2-lane. Command: bash install.sh ar0234cs
8.39MP, 3856×2176, 2-lane. The clock is the crystal on the module. Command: bash install.sh imx908
Contact Camemake.
Driver
5MP sensor in the tested 640×480 mode, 2-lane. GPIO 34 is the power-down pin and stays low. Command: bash install.sh ov5640
Contact Camemake.
Driver
13MP, 4208×3120, 4-lane. The crystal is on the module. Command: bash install.sh ar1335
8MP, 3840×2160, 2-lane. The crystal is on the module. Command: bash install.sh sc835hai
Contact Camemake.
Driver
1MP, 1080×1280, 2-lane. The crystal is on the module. Command: bash install.sh sc132gs
The same Camemake modules, tested on a Luckfox Aura (RV1126B, CSI1). Camemake's European headquarters is in Berlare, Belgium. Install from ROCKCHIP_MIPI_CAMERAS. Other Rockchip boards keep these sensor settings and need their own overlay. Each card links to the sensor maker, the shop page, and that camera's folder.
2.5MP, 2560×1440, 2-lane, link 351 MHz. Copy the gc4023 folder to the board, then sh build.sh and sh install.sh.
2MP, 1928×1088, 2-lane, link 540 MHz.
5MP RGB-IR, 2592×1944, 4-lane, link 450 MHz. The preview looks magenta.
3856×2176, 4-lane, link 720 MHz.
Contact Camemake.
Driver
4MP, 2688×1520, 4-lane, link 180 MHz.
5MP, 2608×1960, 2-lane, link 720 MHz on the Aura.
48MP sensor in the tested 4000×3000 mode, 4-lane, link 450 MHz. The Aura driver is named imx586cm.
2MP global shutter, 1920×1200, 4-lane, link 270 MHz.
Test driver, 1600×1400 global shutter, 2-lane, link 750 MHz. Not an Aura CSI1 picture. Read the folder notes before loading the overlay.
